HDPE Compression Txo Tee
Hauj lwm lawm
Kev tsis
HDPE Compression Fittings, PP compression fittings, HDPE Compression txo tee, Compression tee reducer, Poly Compression txo tee, Compression txo tee fittings, HDPE compression tee reducer, PP Compression txo tee
A HDPE compression txo tee fitting siv rau tee tawm metric HDPE yeeb nkab, txhawm rau ntxiv rau qhov hluav taws xob me me rau sab hauv PE Yeeb. PP Compression tee reducers feem ntau yog siv los xa dej lossis lwm yam dej mus rau ib cheeb tsam los ntawm cov raj xa hluav taws xob loj, vim tias lawv muaj cov dej me me tawm (thiab yog li ntawd tsawg dua ntws) dua li cov kav dej qub.
Nrog rau qhov ntau thiab tsawg los ntawm 25 * 20 * 25 mm txog 110 * 90 * 110 mm, compression txo tee fittings phim cov yeeb nkab uas muaj ntau. HDPE Compression kev txo cov tees yog qhov tsim nyog rau dej thiab lwm yam kua dej zoo ib yam, nrog cov pa nyhav txog 16 bar, txawm li cas los xij qhov no nws txawv nrog qhov ntsuas kub thiab qhov kub ntawm cov yeeb nkab. Txo qis tee compression fittings yog tsim los ntawm cov khoom zoo PP-B uas tiv taus etching los ntawm cov tshuaj lom neeg ntau, thiab rau UV rays, thiab tsim nyog rau siv sab nraum zoov.
Tau tshaj PELD, PEHD, PE40, PE80 thiab PE100 cov kav dej, HDPE compression txo tee fittings kuj tseem yuav paub dua li kev txhim kho txo tees, compression tee reducer fittings lossis poly yeeb nkab hluav taws xob tee koom nrog.
PP compression txo tee fittings yog muaj 5 yam ntxiv:
Kos cim | Feem Lub Npe | Cov khoom siv | Xim |
A | Cap | Zoo siab polypropylene dub co-polymer (PP-B) | Xiav |
B | Clinching nplhaib | POM cob | Dawb |
C | Thaiv thaiv Bush | Zoo siab polypropylene dub co-polymer (PP-B) | Dub |
D | & quot; O" Ntiv nplhaib Gasket | NBR roj hmab | Dub |
E | Lub cev | Zoo siab polypropylene dub co-polymer (PP-B) | Dub |
Lus qhia ntxaws ntxiv raws li hauv qab no:
Khoom | HDPE Compression txo tee, Compression tee reducer, Poly Compression txo tee, Compression txo qis tee fittings, HDPE compression tee reducer, PP Compression txo tee, PP Compression txo tee |
Specification | 25 * 20 * 25mm txog 110 * 90 * 110mm |
Siab kev ntsuas | Ua Haujlwm Siab rau 20 ℃: 20 ~ 63 hli hauv PN16; 75 ~ 110mm hauv PN10 |
Cov khoom siv | Zoo siab polypropylene dub co-polymer (PP-B) |
Xim | Lub cev dub / xiav Cap |
Cov Qauv Tsim Kho | Qhov loj me thiab cov yam ntxwv: ISO 3501/3503/3458/3459. Txhawm rau kom nruab rau ntawm HDPE kav dej: ISO 11922; DIN 8072/8074; Xov (BSP): ISO 7; DIN 2999. |
Cov Khoom Muag Khoom Tshwj Xeeb
HDPE / PP compression txo teefittings tuaj yeem tsim sizing los ntawm 25 * 20 * 25 mm txog 110 * 90 * 110 hli. Qhov loj 20-63mm nrog lub zog ntawm PN16, thiab 75-110mm pa tawm hauv PN10.
Qhov Coob (hli) | Siab Ntsuam Xyuas (bar) | Nyhav (gram / PCS) | Ntim (PCS / CTN) |
25*20*25 | PN16 | 145 | 96 |
32*20*32 | PN16 | 187 | 70 |
32*25*32 | PN16 | 212 | 60 |
40*25*40 | PN16 | 325 | 40 |
40*32*40 | PN16 | 355 | 36 |
50*25*50 | PN16 | 537 | 25 |
50*32*50 | PN16 | 550 | 25 |
50*40*50 | PN16 | 634 | 20 |
63*25*63 | PN16 | 849 | 12 |
63*32*63 | PN16 | 839 | 12 |
63*40*63 | PN16 | 970 | 12 |
63*50*63 | PN16 | 1060 | 10 |
75*50*75 | PN10 | 1256 | 6 |
75*63*75 | PN10 | 1354 | 6 |
90*63*90 | PN10 | 1956 | 4 |
90*75*90 | PN10 | 2098 | 4 |
110*63*110 | PN10 | 4159 | 2 |
110*75*110 | PN10 | 2002 | 2 |
110*90*110 | PN10 | 3549 | 2 |
Cov txiaj ntsig ntawm HDPE Compression Fittings
Muaj ntau cov txiaj ntsig los siv HDPE compression fittings hauv koj cov kav dej. Muaj qee qhov zoo tseem ceeb muaj xws li:
Yooj yim sib dhos thiab rhuav tshem yam tsis tas yuav siv cov cuab yeej tshwj xeeb
Tsis tshua muaj kev saib xyuas nyob rau lub sijhawm, uas ua rau cov kav xa dej mus ntev dua
Tsis muaj soldering yuav tsum tau, uas yog tshwj xeeb rau cov chaw uas tsis muaj kev tiv thaiv soldering
Lub teeb-hnyav hauv qhov sib piv rau lwm cov ntaub ntawv, uas pab ua kom muaj kev sib dhos sai thiab ua tau zoo
Tawv tsis muaj kev sib koom tes yog ua los ntawm cov cov cua kub sib koom ua ke kom paub meej cov sib txuas
Taug-tsis muaj kev sib txuas, muab tau muab kho tau raug
Kev kho xeb tuaj yeem yog vim yog HDPE. Lawv yuav tsis xeb lossis paug tawm, txawm tias tom qab kis tas li los ntawm dej los yog kua
Muaj peev xwm tuav tau cov dej surges vim zoo tshaj plaws dej rauj muaj peev xwm
Tiv Tauj Peb
Yog tias koj muaj kev xav tau ntawm PP compression fittings, lossis cov lus nug ntawm peb cov fittings, thov hu rau peb dawb do. SUNPLAST muaj cov neeg ua haujlwm tau kawm zoo uas muaj los daws koj cov kev xav tau thiab muab kev pab txhawb kev rau txhua lub sijhawm thaum xav tau.
